Degree of protection (NEMA):
-
|
|
Number of poles:
3.000
|
|
Rated operation power at AC-3, 400 V:
10.000
|
|
Number of auxiliary contacts as normally open contact:
1.000
|
|
Number of auxiliary contacts as normally closed contact:
1.000
|
|
Rated permanent current Iu:
32.000
|
|
Rated operating voltage:
-
|
|
Conditioned rated short-circuit current Iq:
-
|
|
Degree of protection (IP), front side:
-
|
|
Number of auxiliary contacts as change-over contact:
0.000
|
|
Number of switches:
1.000
|
|
Interlockable:
true
|
|
Motor drive integrated:
false
|
|
Type of electrical connection of main circuit:
-
|
|
Version as emergency stop installation:
true
|
|
Type of control element:
-
|
|
Version as main switch:
true
|
|
Version as safety switch:
true
|
|
Version as maintenance-/service switch:
true
|
|
Rated operation power at AC-23, 400 V:
12.000
|
|
Rated short-time withstand current lcw:
0.500
|
|
Colour control element:
-
|
|
Suitable for ground mounting:
false
|
|
Suitable for front mounting 4-hole:
false
|
|
Suitable for front mounting centre:
true
|
|
Suitable for distribution board installation:
-
|
|
Suitable for intermediate mounting:
-
|
|
Max. rated operation voltage Ue AC:
690.000
|
|
Motor drive optional:
false
|
|
Voltage release optional:
false
|
|
Device construction:
-
|
|
Rated permanent current at AC-21, 400 V:
32.000
|
|
Switching power at 400 V:
-
|
|
Version as reversing switch:
false
|
|
Rated permanent current at AC-23, 400 V:
22.000
|
